Multistage Pump

Stainless Steel Multistage Pumps — SCMI Series

Stainless Steel Multistage Centrifugal Pumps

Share:

Description

Better design, tougher materials, stronger performance.

It is a multi-purpose pump which is reliable, quiet and compact horizontal pumps.

The pump design makes it easy and durable to make customized solutions.

Eco-friendly and food grade pump for HOT and COLD water systems with whole S.S material for water parts.                                                                                                                                                                  Pumps should be installed in a covered area, protected against water.


Application

Commercial&Domestic Pressure boosting;

Washing and Cleaning;

Heating and Cooling System;

Commercial air conditioning;

Industrial water supply & transfer;

Water distribution ;

Compact, noiseless, reliable and flexible, and these make it an optimal solution for installation and interaction with other components in small and large systems or as a stand-alone pump.


Features

All water parts are Stainless Steel material

Self-priming: 6m

Anti-rust and durable

Series for different performance demand

Multi-material for different applications

Silent running and high efficiency


Performance range

Flow: 1.0~25m3/hour;

Head:10~60m;

Low Fluid temperature:-20~+70℃

Standard Fluid model:+15~+70℃

High Fluid Temperature:70℃~+104℃

Environmental temperature:≤50℃

Max working pressure: 10 BAR


Motor

100% copper wire;

Durable quality with High Efficiency;

Single phase/Three phase both available with 50HZ&60HZ;

Thermal protector for single phase;

Duty: Continuously rated;

Insulation:F

Protection:IP55



Catalogue
